主要性能參數MAIN SPECIFICATIONS

1

叉齒長度Length of fork tines

1220mm

2

額定載荷Rated load

4000 kg

3

動臂提升時間（空載/滿載）
Boom lifting time (no load/full load)

14.4/18.9s

4

動臂下降時間（空載/滿載）
Boom lowering time (no load/full load)

16.9/19.8s

5

伸縮臂伸出/收回時間
Telescopic boom extend/retract time

20.4s/18.8s

6

收翻斗時間
Retracted bucket time

7s

7

車速
Speed

前進Ⅰ檔/后退Ⅰ檔  FⅠ/RⅠ

10km/h

前進Ⅱ檔/后退Ⅱ檔  FⅠ/RⅠ

30km/h

8

蕞小轉彎半徑 鏟斗外側
Min.Turning Radius Outside of Bucket

5500±50mm

9

車長（叉齒平放地面）
Length (Fork tines flat on the ground)

7500±50mm

10

車寬（斗寬）
Width (Bucket width)

2420±10mm

11

車高（駕駛室頂部）
Height (top of cab)

2810±20mm

12

軸距Wheelbase

 3300±10mm

13

輪距Wheel tread

 1980±10mm

14

蕞小離地間隙Min.Ground clearance

 440mm

15

蕞大舉升高度Max.lifting height

17500±50mm

16

操作質量Operating weight

13000Kg

發動機Engine

1

型號 Model

QSF3.8-C140

2

額定功率/額定轉速 Rated power/Speed

104KW /2200r/min

3

排量Displacement

3.8 L

4

標定工況燃油消耗率
Fuel consumption In calibration conditions

230g/kw·h

傳動系統 Transmission system

1

變速箱
Gearbox

型號Model

CA587914S

型式Type

靜液壓Hydrostatic

2

驅動橋
Axle

型號Model

前橋Front/CA599663S
后橋 Rear/CA599664S

型式Type

濕式制動 Wet brake

總減速比Total Deceleration Ratio

20.14

橋荷Axle load

25000kg/25000kg

制動扭矩Braking torque

25120 N.m

3

輪胎

輪胎型號Tire Model

440/80-24

輪胎型式Tire Type

充氣輪胎Pneumatic tire

制動系統Brake system

1

行車制動
Traveling Brake

型式 Type

油浸多盤式液壓制動[濕式制動]
Wet brake

制動壓力Braking pressure

4.4Mpa

2

停車制動
Parking brake

型式 Type

彈簧制動液壓釋放
Spring brake hydraulic release

轉向系統Steering system

1

型式 Type

全液壓轉向
Fully hydraulic steering

2

工作泵Working pump

RB02849089

3

排量Displacement

 63ml/r

4

系統壓力System pressure

20 MPa

5

轉向角 Steering angle

28°
